Lotus Changeable Nozzle
●Lotus Changeable Nozzle
Compact structure, specially designed for dry fountains
Driven by two low-voltage pumps
Large scattering angle and rapid response
Easy installation and maintenance of ejection nozzles
Product Specifications
Material: tempered glass/stainless steel (SUS 304)
Pattern: lotus-shape water film/changeable patterns in dryland
Dimensions of water patterns: height 1.5m/water film coverage 0.3-1.5
|
Technical Parameters/Model No. |
CWB-HD2500 |
|
Article No. |
91003 |
|
LED option |
68007/68008/68009 |
|
Voltage (V) |
DC24 |
|
Power (W) 20 |
20 |
|
Max. jump height (m) |
0.3-1.2 |
|
Max. jump frequency (times/min) |
15 |
|
Max. size of drops |
20 |
|
Communication mode |
DMX512 |
|
Protection grade |
IP68 |
|
Max. adjustable angle (°) |
15 |
|
Control channel |
2 channels: switching channel |
|
Max. working temperature(℃) |
5-37 |
|
Standard wire length (m) |
1.0 |
|
Installation mode(m) |
Overall dimensions(mm) |
|
Weight(kg) |
2.2 |
|
Flow (L/min) |
0.5 |
|
Inlet caliber (inch) |
1/2, rapid connector |
|
Overall dimensions(mm) |
125x254 |
